Sayama mold manufacturing co., ltd.
Why Choose SAYAMA
1
±1μm
accuracy of
mold
processing
2
Mirror finish
micro fluidic
patterns are
made with
hand finishing
3
Optimization
by mold flow
analysis
4
Specialized in super engineering plastic mold and molding
5
Experience of over
50 years
and
2,000 molds
Samples
Sayama's Special Technical Expertise
0.08mm PITCH CONNECTOR
Pin:16×2（0.3mm×0.04mm）
Size: W2.80mm, H2.50mm, D0.50mm
Weight: 0.0025g
Material: LCP
Plastic Injection Needle
Size:32G
Outer diameterΦ0.24 Inner diameterΦ0.07
Material：PEEK
■Produced by Injection Molding (Stable Productivity)
■Rounded Tip (Minimally Invasive)
■Environmentally Friendly
Micro Fluidic /Micro Channels
Details: 400holes 200channels
Channel size: D0.15mm W0.1mm
Hole size: Φ0.5mm
Material: COP
0.025module gear
m＝0.025
0.5mm diameter
Micro Wells (Nano Imprinting)
Size： W3um / Pitch3.4um / H3um
Patterned Area：10㎟~40㎟
Micro Nozzle
Micro MIM process:
micro precision and cost advantage comparing to 3D printing and conventional machining
Contact Us
Saitama-ken, Iruma-shi, Miyadera 756-4
Bringing Japan's proud
"KANAGATA"
to the world stage
